Power Rating:1000 kW
Switching Frequency:Up to 15 kHz
Operating Temperature Range:-40°C to +175°C
Cooling Method:Water-cooled
Insulation Class:H
Input Voltage:380 V AC
Output Current:High
Module Size:Compact design for easy integration
The ABB 5SHX 1000H0003 IGBT Module is designed to deliver unparalleled performance in high-power applications, offering exceptional reliability and efficiency in modern industrial settings.
This module is built with state-of-the-art semiconductor technology, providing superior switching capabilities that are essential for achieving optimal power utilization in automated manufacturing lines.
With an operating temperature range from -40°C to +125°C, it is engineered to withstand harsh industrial environments, ensuring continuous operation under varying conditions.
Featuring a high current capability, the module can handle continuous currents up to 800A and peak currents up to 1200A, making it suitable for demanding applications where power surge is expected.
The inclusion of an efficient air-cooling system ensures optimal heat dissipation, prolonging the life of the module and reducing maintenance requirements. Its IP20 protection level guarantees basic splash resistance, enhancing its durability in industrial environments.
